Integration with OpenID connect

MapStore allows to integrate with OpenID connect services. This allows to use external services to authenticate users in MapStore. This is useful when you have to integrate MapStore with an existing authentication system, or when you want to use a third-party service to authenticate users.

Customizing logo and text in Login Form

For details about the configuration for a specific service, please refer to the corresponding section below. If you want to customize the icon and/or text displayed, you can refer to the documentation of the LoginPlugin.

By default, the authenticationProviders field contains only {"type": "basic", "provider": "geostore"}, which represents the standard login on MapStore using a username and password. With this default configuration, when a user tries to log in, MapStore will display the classic login form.

You can add additional providers to the list (e.g., openid), and they will be included as options in the login window. If you want to remove the login form and only use the added providers, you can remove the geostore entry from the authenticationProviders list.

Generic OpenID Connect configuration

MapStore integrates with any OpenID Connect-compliant provider using a generic OIDC layer. You can configure one or more providers simultaneously - each identified by a name that determines the provider field in localConfig.json and the property prefix in mapstore-ovr.properties.

For each provider you want to enable, you have to:

• configure a client on the identity provider (e.g., create a new client in Keycloak, a credential in Google Console, an app registration in Azure AD, etc.)
• add the provider name to oidc_providers and configure {provider}OAuth2Config.* properties in mapstore-ovr.properties
• add a corresponding entry to authenticationProviders in localConfig.json

Configure OpenID provider client

This step depends on the specific OpenID provider so, please, refer to the specific documentation of the OpenID provider you are using. See the Provider examples section below for step-by-step guides for Microsoft Azure, Google, and Keycloak.

You have to get the following information:

• Client ID: the client id. This is the client id that must be present on the OpenID provider
• Client Secret: the client secret. This is the client secret for the client id on the OpenID provider
• Discovery URL: the discovery URL. This is the URL that contains all the information for the specific service.

Configure the MapStore back-end

In order to configure the generic OpenID provider you have to:

• create/edit mapstore-ovr.properties file (in data-dir or class path) to configure the generic provider this way:

# Register "oidc" as an OIDC provider
oidc_providers=oidc

# Enable the OpenID Connect filter
oidcOAuth2Config.enabled=true

# Client credentials from the OpenID provider
oidcOAuth2Config.clientId=mapstore-server
oidcOAuth2Config.clientSecret=<THE_CLIENT_SECRET>
oidcOAuth2Config.sendClientSecret=true

# Discovery URL: the .well-known/openid-configuration endpoint of the provider
oidcOAuth2Config.discoveryUrl=https://<idp-host>/.well-known/openid-configuration

# Create the user on first login if not already present
oidcOAuth2Config.autoCreateUser=true

# Redirect URIs
oidcOAuth2Config.redirectUri=http://<my-domain-site>/mapstore/rest/geostore/openid/oidc/callback
# Internal redirect URI (can be relative path, e.g. `../../..` to work across domains)
oidcOAuth2Config.internalRedirectUri=http://<my-domain-site>/mapstore

# User name attribute (default: email)
# oidcOAuth2Config.principalKey=email

# Scopes to request (if omitted, MapStore uses the ones from the discovery document)
# oidcOAuth2Config.scopes=openid,email,profile

# Role mapping: claim name that carries roles, and mapping to MapStore roles (ADMIN or USER)
# oidcOAuth2Config.rolesClaim=roles
# oidcOAuth2Config.roleMappings=admin:ADMIN,user:USER
# Default role when no mapping matches
# oidcOAuth2Config.authenticatedDefaultRole=USER

# Group mapping: claim name that carries groups, and mapping to MapStore groups
# oidcOAuth2Config.groupsClaim=groups
# oidcOAuth2Config.groupMappings=my-idp-group:my-mapstore-group
# If an IdP role/group name contains ':' or ',', escape it with a backslash.
# In this .properties file the backslash must be doubled:
# oidcOAuth2Config.groupMappings=landscape\\:read:landscape_read
# oidcOAuth2Config.dropUnmapped=false

# Groups always assigned to every authenticated user, in addition to claim-derived ones.
# Created automatically if they do not exist; not subject to groupMappings/dropUnmapped.
# oidcOAuth2Config.defaultGroups=oidc-users

# Global logout (RP-initiated logout): invoke IdP logout on MapStore logout
# oidcOAuth2Config.globalLogoutEnabled=true
# URI to redirect to after logout (optional, required by some providers)
# oidcOAuth2Config.postLogoutRedirectUri=https://<your-domain>/mapstore/

# PKCE (Proof Key for Code Exchange) recommended for public clients
# oidcOAuth2Config.usePKCE=false

# Bearer token validation strategy: jwt (default), introspection, or auto
# oidcOAuth2Config.bearerTokenStrategy=jwt

# Maximum token age in seconds for bearer JWT validation (0 = disabled)
# oidcOAuth2Config.maxTokenAgeSecs=0

# Access type for authorization (set to "offline" to request a refresh token, e.g. for Google)
# oidcOAuth2Config.accessType=offline

• oidcOAuth2Config.enabled: must be true to activate this provider.
• oidcOAuth2Config.clientId: the client id registered on the OpenID provider.
• oidcOAuth2Config.clientSecret: the client secret for the client id.
• oidcOAuth2Config.discoveryUrl: the .well-known/openid-configuration URL of the provider. All endpoints are auto-discovered from this URL at startup. If the discovery endpoint is unreachable at startup (e.g. the IdP is behind a firewall not accessible from the server), you can omit discoveryUrl and set each endpoint manually:

oidcOAuth2Config.authorizationUri=https://<idp-host>/protocol/openid-connect/auth
oidcOAuth2Config.accessTokenUri=https://<idp-host>/protocol/openid-connect/token
oidcOAuth2Config.checkTokenEndpointUrl=https://<idp-host>/protocol/openid-connect/userinfo
oidcOAuth2Config.idTokenUri=https://<idp-host>/protocol/openid-connect/certs
oidcOAuth2Config.logoutUri=https://<idp-host>/protocol/openid-connect/logout
oidcOAuth2Config.revokeEndpoint=https://<idp-host>/protocol/openid-connect/revoke
oidcOAuth2Config.introspectionEndpoint=https://<idp-host>/protocol/openid-connect/token/introspect

These values correspond to the standard fields in the discovery document and are the same endpoints your browser would resolve via the discovery URL at runtime.

• oidcOAuth2Config.sendClientSecret: if true, the client secret is sent to the token endpoint (required for client_secret_post).
• oidcOAuth2Config.autoCreateUser: if true, the user is created on first login if not already in the MapStore database. Set to false when users are managed by an external service like LDAP.
• oidcOAuth2Config.redirectUri: callback URI registered on the provider; must end with /rest/geostore/openid/oidc/callback (replace oidc with the provider name if using a different name).
• oidcOAuth2Config.internalRedirectUri: the URI MapStore redirects to after login. Can be relative (e.g., ../../..).
• oidcOAuth2Config.principalKey: (optional) claim used as the MapStore username. Default is email.
• oidcOAuth2Config.scopes: (optional) comma-separated scopes to request. If omitted, the ones from the discovery document are used.
• oidcOAuth2Config.rolesClaim: (optional) claim name containing roles to map to MapStore roles (ADMIN or USER).
• oidcOAuth2Config.roleMappings: (optional) comma-separated idp-role:MAPSTORE_ROLE pairs.
• oidcOAuth2Config.authenticatedDefaultRole: (optional) role assigned when no roleMappings entry matches. Allowed values: USER or ADMIN.
• oidcOAuth2Config.groupsClaim: (optional) claim name containing groups to map to MapStore user groups.
• oidcOAuth2Config.groupMappings: (optional) comma-separated idp-group:mapstore-group pairs. Escape : and , in group names with a backslash (doubled in .properties files: \\:).
• oidcOAuth2Config.dropUnmapped: (optional) when false (default), all groups found in the claim are created in MapStore and assigned to the user, even if they have no entry in groupMappings. When true, only groups that have an explicit entry in groupMappings are assigned; unmatched ones are ignored.
• oidcOAuth2Config.defaultGroups: (optional) comma-separated group names always assigned to every authenticated user, in addition to the claim-derived ones. These groups are created automatically if they do not exist and are not subject to groupMappings/dropUnmapped.
• oidcOAuth2Config.globalLogoutEnabled: (optional) if true, invokes RP-initiated logout on the IdP when the user logs out of MapStore.
• oidcOAuth2Config.postLogoutRedirectUri: (optional) URI to redirect to after IdP logout; required by some providers (e.g., Keycloak).
• oidcOAuth2Config.usePKCE: (optional) enables Authorization Code Flow with PKCE. Recommended for public clients. Default is false.
• oidcOAuth2Config.bearerTokenStrategy: (optional) strategy for validating bearer JWTs: jwt (default, JWKS signature verification), introspection (RFC 7662 token introspection, required for opaque tokens), or auto (try JWT first, fall back to introspection).
• oidcOAuth2Config.maxTokenAgeSecs: (optional) maximum accepted age in seconds for bearer JWTs. 0 disables the check.
• oidcOAuth2Config.accessType: (optional) passed as the access_type parameter in the authorization request. Set to offline to request a refresh token (required by Google).

Configure the MapStore front-end

• Add an entry for oidc in authenticationProviders inside localConfig.json file.

{
    "authenticationProviders": [
      {
        "type": "openID",
        "provider": "oidc",
        "title": "My custom identity provider"
      },
      {
        "type": "basic",
        "provider": "geostore"
      }
    ]
}

{
"type": "openID",
"provider": "oidc",
"title": "My custom identity provider",
}

{
  "type": "openID",
  "provider": "oidc",
  "showAccountInfo": true
}

Multiple simultaneous providers

You can run multiple OIDC providers at the same time by listing them in oidc_providers (comma-separated) and configuring each with its own {provider}OAuth2Config.* prefix. Each provider's redirectUri must include the provider name in the path.

Example: Keycloak + Google

# Both providers active simultaneously
oidc_providers=keycloak,google

# Keycloak
keycloakOAuth2Config.enabled=true
keycloakOAuth2Config.clientId=mapstore-server
keycloakOAuth2Config.clientSecret=<KEYCLOAK_SECRET>
keycloakOAuth2Config.discoveryUrl=https://keycloak.example.com/realms/myrealm/.well-known/openid-configuration
keycloakOAuth2Config.redirectUri=https://my.mapstore.site.com/mapstore/rest/geostore/openid/keycloak/callback
keycloakOAuth2Config.internalRedirectUri=https://my.mapstore.site.com/mapstore/
keycloakOAuth2Config.autoCreateUser=true

# Google
googleOAuth2Config.enabled=true
googleOAuth2Config.clientId=<GOOGLE_CLIENT_ID>
googleOAuth2Config.clientSecret=<GOOGLE_CLIENT_SECRET>
googleOAuth2Config.discoveryUrl=https://accounts.google.com/.well-known/openid-configuration
googleOAuth2Config.redirectUri=https://my.mapstore.site.com/mapstore/rest/geostore/openid/google/callback
googleOAuth2Config.internalRedirectUri=https://my.mapstore.site.com/mapstore/
googleOAuth2Config.autoCreateUser=true
googleOAuth2Config.accessType=offline

localConfig.json: both providers listed:

{
    "authenticationProviders": [
      {
        "type": "openID",
        "provider": "keycloak",
        "title": "Keycloak"
      },
      {
        "type": "openID",
        "provider": "google",
        "title": "Google"
      },
      {
        "type": "basic",
        "provider": "geostore"
      }
    ]
}

Provider examples

The following sections show complete configurations for three common providers. Each is a specific instance of the generic OIDC layer described above — the configuration structure is the same across all providers.

Microsoft Azure (Entra ID)

Microsoft Azure (Entra ID) provides OpenID Connect support. Please refer to the Microsoft Azure documentation for details.

Configure Azure app registration

Here a quick summary of the steps to configure Microsoft Azure as an OpenID provider and get the information needed to configure MapStore:

1. Create a new application
2. Set the proper valid redirect URLs to: https://<your-domain>/mapstore/rest/geostore/openid/oidc/callback
3. Create and copy the client secret
4. Add optional claims (e.g. email, family_name, given_name) in Token configuration if needed
5. Copy endpoints and data to configure MapStore

From the Azure app registration you need three values:

Configure MapStore back-end for Azure

mapstore-ovr.properties:

oidc_providers=azure

azureOAuth2Config.enabled=true
azureOAuth2Config.clientId=<APPLICATION_CLIENT_ID>
azureOAuth2Config.clientSecret=<CLIENT_SECRET_VALUE>
azureOAuth2Config.sendClientSecret=true
azureOAuth2Config.discoveryUrl=<OPENID_CONNECT_METADATA_DOCUMENT_URL>
azureOAuth2Config.autoCreateUser=true
azureOAuth2Config.redirectUri=https://<your-domain>/mapstore/rest/geostore/openid/azure/callback
azureOAuth2Config.internalRedirectUri=https://<your-domain>/mapstore
note: GroupMember.Read.All scope is required to get group info in the token for group mapping
azureOAuth2Config.scopes=openid,email,profile

If you need to assign groups to users from Azure, add the GroupMember.Read.All scope to the API permissions and grant admin consent. This allows group information to be included in the token for group mapping, and enable msGraphEnabled and msGraphGroupsEnabled to get group info from Microsoft Graph.

# replace this property
azureOAuth2Config.scopes=openid,email,profile,GroupMember.Read.All
# add these properties to enable group retrieval from Microsoft Graph
azureOAuth2Config.msGraphEnabled=true
azureOAuth2Config.msGraphGroupsEnabled=true

# These properties will be available from geostore 2.7
# This forces to have groups resolved from Microsoft Graph also if the groups claim is present in the token, to avoid the issue of Azure AD not emitting group claims when a user belongs to too many groups (over 200). With this setting, group mapping will work even for users with a large number of groups, as all group information will be retrieved from Microsoft Graph instead of relying on the token claims.
# oidcOAuth2Config.msGraphAlwaysResolveGroups=false
# This allows to customize the URL, if changes in the future
# oidcOAuth2Config.msGraphEndpoint=<https://graph.microsoft.com/v1.0>
# This allows to enable role retrieval from Microsoft Graph, if you use App Roles for role mapping instead of group claims. This is also recommended to avoid the issue of Azure AD not emitting role claims when a user belongs to too many groups (over 200), as role information will be retrieved from Microsoft Graph instead of relying on the token claims.
# oidcOAuth2Config.msGraphRolesEnabled=false

Configure MapStore front-end for Azure

configs/localConfig.json.patch ( with a custom title and an image with the Microsoft logo to show in the login form)

    [    {
        "op": "add",
        "path": "/authenticationProviders",
        "value": [
                {
                    "type": "openID",
                    "provider": "oidc",
                    "title": "Microsoft",
                },
                {
                    "type": "basic",
                    "provider": "geostore"
                }
            ]

    }
]

Role mapping via Azure App Roles

The recommended approach for mapping MapStore roles in Azure is to use App Roles defined in the application registration. This avoids the group GUID and 200-group-overage limitations of the groups claim and produces a clean roles claim directly in the ID token.

Step 1: Create an App Role in the Azure app registration

1. In the App Registration → App roles → Create app role
2. Set Display name and Value to ADMIN (the value is what appears in the token)
3. Set Allowed member types to Users/Groups
4. Enable the role and save

Step 2: Assign the role to users or groups

1. Go to Enterprise Applications → select your application → Users and groups → Add user/group
2. Select the user (or group) and assign the ADMIN role

With this configuration the ID token will contain a roles claim like:

{
  "roles": ["ADMIN"],
  "email": "user@example.com"
}

Step 3: Configure MapStore to read the roles claim

Add role mapping to mapstore-ovr.properties:

# Map the Azure 'roles' claim to MapStore roles
oidcOAuth2Config.rolesClaim=roles
oidcOAuth2Config.roleMappings=ADMIN:ADMIN
# Users without a matching role get USER by default
oidcOAuth2Config.authenticatedDefaultRole=USER

Group mapping in Azure

By default the groups claim in the Azure ID token contains Object ID GUIDs, not display names. To emit display names instead, edit the application Manifest (App Registration → Manifest) and set:

{
  "groupMembershipClaims": "ApplicationGroup",
  "optionalClaims": {
    "idToken": [{
      "name": "groups",
      "additionalProperties": ["cloud_displayname"]
    }]
  }
}

Once display names are emitted, configure MapStore to read them:

oidcOAuth2Config.groupsClaim=groups
oidcOAuth2Config.groupMappings=<azure-group-display-name>:<mapstore-group-name>

Google

Google OpenID Connect is configured as a named OIDC provider using the generic OIDC layer.

Create Oauth 2.0 credentials on Google Console

In order to setup the openID connection you have to setup a project in Google API Console to obtain Oauth 2.0 credentials and configure them. Here a quick summary of the steps to configure Google as an OpenID provider. For more details, please refer to the Google documentation.

• Open the Google developer console and, from credentials section, create a new credential of type Oauth client ID

• Set the Application Type to Web Application, name it as you prefer and configure the root of the application as an authorized redirect URI. Then click on Create

• After creation you will obtain ClientID and Client Secret to use to configure MapStore.

Please follow the Google documentation for any detail or additional configuration.

Configure MapStore back-end for Google OpenID

After the setup, you will have to:

• create/edit the mapstore-ovr.properties file (in data-dir or class path) to configure the Google OpenID integration. Use the provider name google so that the callback URL matches:

# Register "google" as an OIDC provider
oidc_providers=google

# Enable the Google OpenID Connect filter
googleOAuth2Config.enabled=true

# Client credentials from Google Developer Console
googleOAuth2Config.clientId=<the_client_id_from_google_dev_console>
googleOAuth2Config.clientSecret=<the_client_secret_from_google_dev_console>

# Create the user if not already present in MapStore
googleOAuth2Config.autoCreateUser=true

# Redirect URL (must be registered in Google Console too)
googleOAuth2Config.redirectUri=https://<your-application-domain>/mapstore/rest/geostore/openid/google/callback
# Internal redirect URI (can be relative, e.g. `../../..` to work across domains)
googleOAuth2Config.internalRedirectUri=https://<your-application-domain>/mapstore/

# Discovery URL for Google's OIDC endpoints
googleOAuth2Config.discoveryUrl=https://accounts.google.com/.well-known/openid-configuration

# Request a refresh token (required for long-lived sessions with Google)
googleOAuth2Config.accessType=offline

Configure MapStore front-end for Google OpenID

• Add an entry for google in authenticationProviders inside localConfig.json file.

{
    "authenticationProviders": [
      {
        "type": "openID",
        "provider": "google"
      },
      {
        "type": "basic",
        "provider": "geostore"
      }
    ]
}

Keycloak

Keycloak is an open source identity and access management application widely used. MapStore integrates with Keycloak via the generic OIDC layer.

Configure Keycloak Client

Create a new Client on Keycloak. In this guide we will name it mapstore-server (if you also need SSO, you will create a second client called mapstore-client).

• Configure it as Confidential, setting the Redirect URL to your MapStore base root with a * at the end (e.g. https://my.mapstore.site.com/mapstore/*)

Note the realm and auth-server-url from Keycloak, you will use them to build the discoveryUrl.

Configure MapStore back-end for Keycloak OpenID

Create/edit mapstore-ovr.properties file (in data-dir or class path) to configure the Keycloak provider:

# Register "keycloak" as an OIDC provider
oidc_providers=keycloak

# Enable the Keycloak OpenID Connect filter
keycloakOAuth2Config.enabled=true

# Client credentials from Keycloak
keycloakOAuth2Config.clientId=mapstore-server
keycloakOAuth2Config.clientSecret=<CLIENT_SECRET>
keycloakOAuth2Config.sendClientSecret=true

# Discovery URL: <auth-server-url>/realms/<realm>/.well-known/openid-configuration
keycloakOAuth2Config.discoveryUrl=https://keycloak.example.com/realms/myrealm/.well-known/openid-configuration

# Redirect URLs
keycloakOAuth2Config.redirectUri=https://my.mapstore.site.com/mapstore/rest/geostore/openid/keycloak/callback
keycloakOAuth2Config.internalRedirectUri=https://my.mapstore.site.com/mapstore/

# Create user on first login (set to false if users come from LDAP or another external source)
keycloakOAuth2Config.autoCreateUser=true

# Scopes to request: explicitly set to avoid requesting offline_access by default,
# which requires the Keycloak client/user to have the offline_access role configured.
keycloakOAuth2Config.scopes=openid,profile,email

# Role mapping: dot-notation path to the claim carrying roles, and mapping to MapStore roles (ADMIN or USER)
keycloakOAuth2Config.rolesClaim=realm_access.roles
keycloakOAuth2Config.roleMappings=admin:ADMIN,user:USER
# Default role when no mapping matches
keycloakOAuth2Config.authenticatedDefaultRole=USER

# Group mapping: claim name that carries groups, and mapping to MapStore groups
keycloakOAuth2Config.groupsClaim=groups
keycloakOAuth2Config.groupMappings=MY_KEYCLOAK_GROUP:MY_MAPSTORE_GROUP,MY_KEYCLOAK_GROUP2:MY_MAPSTORE_GROUP2
# false (default) = all groups from the claim are created and assigned; true = only mapped ones
keycloakOAuth2Config.dropUnmapped=false

# Groups always assigned to every authenticated user (created on the fly if missing)
# keycloakOAuth2Config.defaultGroups=keycloak-users

# RP-initiated global logout
# keycloakOAuth2Config.globalLogoutEnabled=true
# keycloakOAuth2Config.postLogoutRedirectUri=https://my.mapstore.site.com/mapstore/

• oidc_providers=keycloak: registers the keycloakOAuth2Config bean; required in geostore 2.6+.
• keycloakOAuth2Config.discoveryUrl: the Keycloak OIDC discovery URL - <auth-server-url>/realms/<realm>/.well-known/openid-configuration. This replaces the old keycloakOAuth2Config.jsonConfig.
• keycloakOAuth2Config.redirectUri: must end with /rest/geostore/openid/keycloak/callback.
• keycloakOAuth2Config.internalRedirectUri: the MapStore home page URI after login.
• keycloakOAuth2Config.autoCreateUser: true to create DB users on first login; false when using LDAP or external user stores.
• keycloakOAuth2Config.roleMappings: comma-separated keycloak-role:MAPSTORE_ROLE pairs. Allowed MapStore values: USER or ADMIN.
• keycloakOAuth2Config.authenticatedDefaultRole: role applied when no roleMappings entry matches.
• keycloakOAuth2Config.groupMappings: comma-separated keycloak-group:mapstore-group pairs.
• keycloakOAuth2Config.dropUnmapped: false (default) creates and assigns all groups from the claim, even unmapped ones; true assigns only groups with an explicit entry in groupMappings.
• keycloakOAuth2Config.defaultGroups: (optional) comma-separated group names always assigned to every authenticated user.

Configure MapStore front-end for Keycloak OpenID

• Add an entry for keycloak in authenticationProviders inside localConfig.json file.

{
    "authenticationProviders": [
      {
        "type": "openID",
        "provider": "keycloak"
      },
      {
        "type": "basic",
        "provider": "geostore"
      }
    ]
}

Role and group mapping in Keycloak

Role mapping

GeoStore supports only two roles: ADMIN and USER. The simplest approach is to set authenticatedDefaultRole=USER and promote admin users manually through the MapStore UI.

If you want the token to drive admin assignment automatically, set rolesClaim to point at the claim that carries roles. MapStore supports dot-notation paths for nested claims, so you can reference Keycloak's default realm_access.roles structure directly:

keycloakOAuth2Config.rolesClaim=realm_access.roles
keycloakOAuth2Config.roleMappings=admin:ADMIN,user:USER
keycloakOAuth2Config.authenticatedDefaultRole=USER

Alternatively, add a User Realm Role protocol mapper in Keycloak to emit a flat top-level claim and use that instead. In the Keycloak Admin Console, go to Clients → mapstore-server → Client scopes → mapstore-server-dedicated → Add mapper → By configuration → User Realm Role, then set:

This produces "roles": ["admin", "user"] at the token root:

keycloakOAuth2Config.rolesClaim=roles
keycloakOAuth2Config.roleMappings=admin:ADMIN,user:USER
keycloakOAuth2Config.authenticatedDefaultRole=USER

Group mapping

Add a Group Membership mapper in the same client scope:

This produces "groups": ["my-group", "another-group"] with display names (no leading /). Configure MapStore:

keycloakOAuth2Config.groupsClaim=groups
keycloakOAuth2Config.groupMappings=my-keycloak-group:my-mapstore-group
# false = all groups from claim created/assigned; true = only mapped ones
keycloakOAuth2Config.dropUnmapped=false
